DLT-PJ9000 PTFE-coated fiberglass membrane is an architectural fabric for tensile roofs, canopies, atriums and building facades. Its 1600gsm construction combines an EC6 fiberglass base with a multilayer PTFE coating. Use the technical datasheet below to compare fabric width, thickness, tensile strength and light transmission with your project requirements.
PTFE fiberglass membrane supplier that provides fiberglass membrane coated with PTFE produces a photocatalytic membrane that functions like the leaves of a tree, providing shade and comfort while actively neutralizing airborne pollutants and odors. Coated PTFE is a popular choice with designers and architects in sustainable commercial roofing market sectors throughout Asia and is now beginning to find its niche in custom tensile systems in North America. The unique self-cleaning benefits of fiberglass membrane allow the material to break down dirt and other organic materials through a chemical reaction with the sun’s UV rays, oxygen and water vapor, present in the air. This reaction, known as oxidation-reduction, converts these materials into harmless gases and natural components without using excess chemicals, solvents or water. The resulting sediments are simply washed away by rain. As a result, the membrane material remains bright and clean, reducing the need for frequent service.
Fiberglass membrane specifications:
| PTFE fiberglass membrane | DuraSuntex DLT-PJ9000 | |
| Technology: | Muti layer PTFE (Teflon) coating |
| Base fabric | Fiberglass filaments EC6 |
| Surface: | Matte |
| Colour: | Eeige (Will transform into white colour after completed bleaching ) |
| Weight: | 1600gsm |
| Width： | 3-3.8meter |
| Thickness: | 0.85mm |
| Tensile strength: | 9300 (N/5cm) Warp / 9000 (N/5cm) Weft |
| Adhesion: | 70 (N/5cm) |
| Light transmission at 550nm: | 16-25% |
| Flame retardent: | B1/B-S1; d0 (DIN4102/EN 13501) |
| Welding methods: | Hot bar welding/FEP welding tape |
| Life span: | 25years |
| Suitable temperature: | -100°F to +450°F (-73°C to +232°C) |
Fiberglass membrane features
- Lifespan exceeding 30 years
- Can withstand temperatures of -100 F to +450 F (-73 C to +232 C)
- Tensile strength of 500,000 PSI (more than 10 times the tensile strength of steel)
- Chemically inert
- Weather-resistant
- Resistant to micro-organisms
- Moisture-resistant
- Immune to UV degradation
- Resists the build-up of environmental pollution
- Does not discolor over time
- Does not become brittle over time
- Environmental benefits of PTFE coated fiberglass
- Self-cleaning with rain water
Fiberglass membrane applications
- Stadiums
- Exhibition spaces
- Museums
- Transportation hubs
- Leisure
- Retail
- Projects located in tropical, arid or extreme cold climates
- Large, complex structures
- Courtyards
- Atriums
- Enclosed structures
- Fabric building facades
- Vertical building facades
- Shading applications
- High-rise rooftop decks
FEP WELDING FOR DLT-PJ9000
Fabrication of DLT-PJ9000 PTFE-coated fiberglass membrane uses 0.8mm FEP welding strip. When planning tensile architectural panels, specify the welding process together with the fabric grade and seam layout.
High-frequency welding
Use a dedicated high-frequency welding machine with a current setting of 1.0–1.2A and a welding time of 8–10sec.
Hot-air welding
The separate hot-air process uses 550°C and a travel speed of 4–5m/min. The two processes use their respective settings: current and time for high-frequency welding, temperature and speed for hot-air welding.
For DLT-PJ9000 supply and fabrication enquiries, include panel drawings, quantity, seam layout and equipment type. Read the PTFE-coated fiberglass fabrication guide or request a quotation for DLT-PJ9000.
