Fiberglass roller shade is a length of fabric on a roller mechanism that can be adjusted to different heights. It is an economical way to control privacy and glare. There is 3 types of roller blind: Blackout, Screen fabrics, Light filtering. The ever popular fiberglass roller shade comes with the chain control as a standard feature. Rollers have never looked more appealing and are available in a large range of colors and performance fabrics with an aluminium bottom bar or decorator trims. Available with color coordinated brackets, Our Rollers can even be matched with Verticals, Romans and Panel Glides to provide the complete design solution.
Fiberglass roller shade specifications:
Fiberglass standard | DuraBlinds DLT-1004 | |
Structure: | 4-Layer: PVC+PVC black fim+Fiber Glass+PVC |
Width: | 1.02m-3.2m |
Weight: | 560g(±10g)/sqm |
Thickness: | 0.43mm± 0.01mm |
Blockout rate: | Blackout (Complies to AS 2663.3.1999) |
Color fastness: | 5-6 (Blue Scale) Tested to ISO 105-B02:2014 |
Flame retardant: | California U.S. Title 19 (small scale), NFPA 701-2010 TM#1 (small scale), BS 5867 2008 Part 2 Type B Performance. |
Tensile strength: | ≥2000 N/5cm DIN53354 Zonal N/5cm |
Tear strength: | ≥80 N/5cm DIN53363 Zonal N/5cm |
Peel off strength: | ≥80 N/5cm DIN53357 Zonal N/5cm |
Suitable temperature: | -20° to +70° |
Package: | Inner packing: hardboard tube and kraft paper/ poly bag Outer packing: hardboard tube and tube cover |
Meter per roll: | 30m |
Light & Solar Optical Properties
Colours | SolarTransmittance | Solar Reflectance | Solar Absorbance | Visible Light Transmittance | UV Transmittance | Openness Factor |
White | 0% | 71% | 29% | 0% | 0% | 0% |
Ivory | 0% | 71% | 29% | 0% | 0% | 0% |
Grey | 0% | 70% | 28% | 0% | 0% | 0% |
Black | 0% | 4% | 96% | 0% | 0% | 0% |
Shading Coefficient | G-Value | |||||
Colours | 3mm CI. | 6mm CI. | 6mm H.A. | 3mm CI. | 6mm CI. | 6mm H.A. |
White | 0.28 | 0.26 | 0.28 | 0.24 | 0.26 | 0.26 |
Ivory | 0.28 | 0.26 | 0.28 | 0.24 | 0.24 | 0.25 |
Grey | 0.24 | 0.25 | 0.25 | 0.25 | 0.26 | 0.26 |
Black | 0.72 | 0.72 | 0.66 | 0.62 | 0.62 | 0.57 |
