Fiberglass membrane coated with PTFE produces a photocatalytic

Description

Fiberglass membrane coated with PTFE produces a photocatalytic membrane that functions like the leaves of a tree, providing shade and comfort while actively neutralizing airborne pollutants and odors. Coated PTFE is a popular choice with designers and architects in sustainable commercial roofing market sectors throughout Asia and is now beginning to find its niche in custom tensile systems in North America. The unique self-cleaning benefits of fiberglass membrane allow the material to break down dirt and other organic materials through a chemical reaction with the sun’s UV rays, oxygen and water vapor, present in the air. This reaction, known as

idation-reduction, converts these materials into harmless gases and natural components without using excess chemicals, solvents or water. The resulting sediments e simply washed away by rain. As a result, the membrane material remains bright and clean, reducing the need for frequent service.

Fiberglass membrane specifications:

PTFE fiberglass membrane \| DuraSuntex DLT-PJ7500
Technology:	Muti layer PTFE (Teflon) coating
Base fabric	Fiberglass filaments EC6
Surface:	Matte
Colour:	Eeige (Will transform into white colour after completed bleaching )
Weight:	1450gsm
Width：	3-3.8meter
Thickness:	0.8mm
Tensile strength:	7500 (N/5cm) Warp / 7300 (N/5cm) Weft
Tearing strength:	520 (N/5cm) Warp / 510 (N/5cm) Weft
Adhesion:	70 (N/5cm)
Light transmission at 550nm:	16-25%
Flame retardent:	B1/B-S1; d0 (DIN4102/EN 13501)
Welding methods:	Hot bar welding/FEP welding tape
Life span:	25years
Suitable temperature:	-100°F to +450°F (-73°C to +232°C)
