Clear TPU film is a flexible thermoplastic polyurethane film for lamination and fabrication. Duletai supplies film in thicknesses of 0.1mm–0.8mm and widths of 1.0m–2.5m. Specify the required transparency, hardness and processing method when requesting a sample or quotation.
POLYETHER AND POLYESTER TPU:
TPU is available in polyether and polyester types, each with characteristics suited to different requirements. Polyester TPU provides high resistance to chemicals and oils. Polyether TPU offers excellent flexibility and tear resistance, with hydrolysis resistance suited to prolonged water exposure. The base chemistry changes the physical performance of the TPU substrate.
TPU resins differ from other soft-touch materials through their inherent performance characteristics. Their versatility supports use across automotive, sporting goods, wire and cable, and footwear industries.
FABRICATION PERFORMANCE:
Clear TPU film is easy to vacuum form, print and high-frequency weld. Good UV stability, excellent hydrolysis resistance, and resistance to low and high temperatures support demanding applications. Transparent, semitransparent and opaque options are listed in the datasheet below.
TECHNICAL DATASHEET:
| Clear TPU film | |
|---|---|
| Material | TPU |
| Hardness | Soft |
| Transparency | Transparent,semitransparent and opaque |
| Thickness | 0.1mm-0.8mm |
| Width | 1.0-2.5meter |
| PHR | 30-80 |
| Anti-UV Grade | Grade 4 |
| Melt Point | 135-175 ℃ |
| Gravity | (g/cm3) 1.11-1.21 |
| Packing | PE foam or kraft paper with clear film or color film; |
ENVIRONMENTAL CHARACTERISTICS:
Please include any recycling, restricted-substance or end-of-life requirements when requesting a grade. Ask for supporting documentation for the material supplied.
Clear TPU film features:
- Transparent, semitransparent and opaque film options.
- Polyether and polyester TPU types for different application requirements.
- Thickness, width and hardness selected for the fabrication process.
- Lamination, vacuum forming, printing and high-frequency welding requirements can be reviewed with a sample.
- Specify abrasion resistance, low-temperature flexibility, hydrolysis resistance and any oil or chemical exposure for the selected grade.
Clear TPU film applications:
The unique performance characteristics also make TPU the preferred base substrate for a variety of performance applications:
- Medical fabrics
- Smart clothing
- Water resistant, breathable textiles
- Membranes
- Bladders
- Automotive protection films
- Surfacing applications
- Tape backing film
- Mountaineering Jacket
- Lace laminate
- Fabric laminated
- Fashion clothing and handbags
- Aprons, raincoats, kite bladders, air bags and airships
- Water ball、Transparent tent、Shoes、The disposable surgical cases、The medical mattress、Drinking water bag
Product List: » PVC Free Material »
SELECT CLEAR TPU FILM:
Begin with the intended application and processing method, then specify film thickness, width, transparency and hardness. Include whether the project involves extended water exposure, oil or chemical contact, lamination, vacuum forming, printing or high-frequency welding.
Request clear TPU film samples or a quotation with your material requirements, quantity and destination. You can also explore our TPU film specifications and applications.
