Description
Views: 506
Plastic curtains material which is hard wearing, impact resistent. Widly used for vinyl swing door ,freezer plastic curtains and PVC impact door curtain, function as blance weight and impact protection. Extent the life spam of the door. Impact doors are an economical solution when unimpeded traffic is necessary. Typically composite and can handle repeated cycles of impact from pallet jacks and forklifts. They customarily have “gravity” hinges that allow them to close without using springs, hydraulics or electrical devices, making them less costly to purchase and maintain. Most are equipped with vision lights for safety, as well as guards and impact swing door material to protect the door and take the abuse at impact points. They can be sealed to conform to the requirements of the USDA, FDA, temperature, dust containment or any other barrier requirements. Plastic curtains material is laminated with 5LAYERS in the order of PVC FILM+BASE FABRIC+PVC FILM+BASE FABRIC+PVC FILM. This technic made the material extrmely tuff and hard wearing. Meanwhile the heavy weight plastic curtains material is a blance weight for the strip curtain bottom as a “draw down bar” it can maintain the plastic curtains straight.
Plastic curtains material specifications:
High speed door fabric | DuraTarps DLT-5804 | |
Technology: | Laminated |
Structure: | 5LAYERS [PVC FILM+BASE FABRIC+PVC FILM+BASE FABRIC+PVC FILM] |
Base fabric: | 1000D*1000D |
Weight: | 2000gsm |
Thickness: | 3.0mm |
Width: | 1.05-3.2m |
Roll length: | 50m/100m |
Surface: | Glossy/Matte |
Blockout: | Extra blockout layer available |
Tensile Strength | 4000/4000 N/5cm DIN53354 |
Tear Strength | 600/500 N/5cm DIN53356 |
Adhesion | 100 N/5cm DIN53357 |
Colour: | Customized |
Temperature: | -20~+70(°C) |
FR certification: | Customized B1, B2, M1, M2, NFPA701, DIN75200; |
Surface: | Double side acrylic larquered, Tear-Resistant, Waterproof |
Packing: | Paper tube+PE film+Craft paper |
MOQ: | 3000meters for customization/ |
-
Features
Hot-melt Coating technology(Semi-coating).
Good peeling strength for welding.
Outstanding tearing strength.
Flame retardant character.(optional)
Anti ultraviolet treatment(UV).(optional)
Acrylic treatment (optional).
Temperature resistance: -20–70
Applications
- Draffic door Impact Doors
- Impact Traffic Door
- Rubbair Doors
- Ruff Tuff Doors
- Traffic Doors for Supermarkets
