Description
Hits: 794
Fiberglass window shade offers quality and lasting solutions for solar protection for both business and residential buildings. This range of fiberglass window shade are developed using woven fiberglass yarns with a coating that ensures all products provide durable tensile strength and offer both dimensional and colour stability. Solar protection using fiberglass window shade offers high protection while maintaining the natural, incoming light for optimal visual and thermal comfort. Fiberglass window shadeis widly used in home decoration, office building, airport, shopping mall and hospitals.The blackout roller blinds PVC fiberglass roller blinds fabric is made of 25% fiberglass 75% PVC laminated (1 ply fiberglass, 3 ply PVC). We use fiberglass fabric as basic cloth, laminating with PVC vinyl film by special technique that has excellent performance for UV blockage, waterproof, fire-retardant and mildew proof. With superior heat and reflection properties it assists in maintaining an energy-efficient environment comfortable living environment. Our material is suitable for both roller and panel blinds. The nature of PVC ensures that the collection is durable, moisture-resistant and long-lasting while still retaining an attractive appearance.
Fiberglass window shade specifications:
| Fiberglass Lite | DuraBlinds DLT-1101 White | |
| Color: | White |
| Structure: | 4-Layer: PVC+PVC black fim+Fiber Glass+PVC |
| Width: | 1.02m-2.5m |
| Weight: | 420g(±10g)/sqm |
| Thickness: | 0.34mm± 0.01mm |
| Blockout rate: | Blackout (Complies to AS 2663.3.1999) |
| Color fastness: | 5-6 (Blue Scale) Tested to ISO 105-B02:2014 |
| Flame retardant: | California U.S. Title 19 (small scale), NFPA 701-2010 TM#1 (small scale), BS 5867 2008 Part 2 Type B Performance. |
| Tensile strength: | ≥2000 N/5cm DIN53354 Zonal N/5cm |
| Tear strength: | ≥80 N/5cm DIN53363 Zonal N/5cm |
| Peel off strength: | ≥80 N/5cm DIN53357 Zonal N/5cm |
| Suitable temperature: | -20° to +70° |
| Package: | Inner packing: hardboard tube and kraft paper/ poly bag Outer packing: hardboard tube and tube cover |
| Meter per roll: | 30m |
Light & Solar Optical Properties
| Colours | SolarTransmittance | Solar Reflectance | Solar Absorbance | Visible Light Transmittance | UV Transmittance | Openness Factor |
| White | 0% | 71% | 29% | 0% | 0% | 0% |
| Ivory | 0% | 71% | 29% | 0% | 0% | 0% |
| Grey | 0% | 70% | 28% | 0% | 0% | 0% |
| Black | 0% | 4% | 96% | 0% | 0% | 0% |
| Shading Coefficient | G-Value | |||||
| Colours | 3mm CI. | 6mm CI. | 6mm H.A. | 3mm CI. | 6mm CI. | 6mm H.A. |
| White | 0.28 | 0.26 | 0.28 | 0.24 | 0.26 | 0.26 |
| Ivory | 0.28 | 0.26 | 0.28 | 0.24 | 0.24 | 0.25 |
| Grey | 0.24 | 0.25 | 0.25 | 0.25 | 0.26 | 0.26 |
| Black | 0.72 | 0.72 | 0.66 | 0.62 | 0.62 | 0.57 |
 |
 |
 |
 |
Fiberglass window shade features:
Fiberglass window shade versions:
We have developed 2 types of window curtain fabrics with fiberglass core. DLT-1100 series Low desity base fabric(Lite) and DLT-1000 series High desity base fabric (Standard). These 2 versions all have the same function and life time, difference is the lite version DLT-1100 surface is fiber textured and standard version DLT-1000 surface is smooth. And the weight is different according to the follow spec of the 2 version.
