Blockout PVC Tarpaulin PVC coated fabric 100% opaque

Blockout PVC tarpaulin is PVC coated fabric 100% opaque. It is designed for marquees and tents for events. Blockout PVC tarpaulin, which has a very high thermal deflection ratio, ensures optimum comfort in areas with strong sunlight. The opacity is the blockout tarpaulin’s major asset. The intermediate layer prevents show through of the image from the respective opposite side, thereby assuring maximum impact of the graphics on both sides. The Blockout PVC tarpaulin is made of polyvinyl chloride (PVC). The material is heavy, robust and extremely tear-proof, making it ideal for long-term use outdoors. The smooth surface on both sides yields brilliant colours. The tarpaulin is without structure and has a smooth feel. The material can be wiped clean with a gentle cleaning agent and water.Thanks to its outstanding weather-resistance, the material is suitable for both indoor and outdoor use. It is particularly rugged and durable. Large size structures may be made, due to its mechanical strength. Now available in grain and 3D finish. Blockout tarpaulin is a reliable weather-resistant material for both short- and long-term advertising campaigns. The tarpaulin is light-proof, due to which the printed motif remains non-distorted and is well-visible from all sides. To make sure that the tarpaulin remains in place even in bad weather, we supply it with customised eyelets. Our Smooth Block out Vinyl presents your artwork in a premium fashion. Its non-transparent property fits best in heavily-lit areas and outdoor settings. The elegantly smooth finish makes it appropriate for any style of event with any budget. Width up to 5.1m

Blockout PVC Tarpaulin Specifications

Item: 650GSM 1000D 9×9

Base Fabric Yarn	Denier		1000 x 1000D
Base Fabric Density	Thread/inch	FZ/T01003	9×9
Finished Fabric Weight	Gram/m2	FZ/T01003	650
Tensile strength at MD	N/5cm	GB/T1040	1600
Tensile strength at CD	N/5cm	GB/T1040	1300
Tearing Strength at MD	N/20cm	GB/T16578	395
Tearing Strength at CD	N/20cm	GB/T16578	345
Peeling Strength	N/5cm	GB/T3917	48
Temperature range	ºC		-25 ~ +70
Flame retardancy		NFPA-701	Optional
Anti UV			3years
Flame retardancy		NFPA-701,B1 ,B2,M1.M2 ,	Optional
Environmental		E N – 7 1 , R o H s	Optional
MOQ	M	2500LM
Packing		Kraft paper
Lead time		20-25days

Item: 850GSM 1100D 23X23

Base Fabric Yarn	Dtex	High tenacity polyester 1100 Dtex
Finish:	Gloss
Coating	PVC coating
Color	White Block out
Base Fabric Density	Thread/cm	FZ/T01003	23×23
Finished Fabric Weight	Gram/m2	FZ/T01003	850±5%
Thickness – finished product	mm	GB/T6672-2001	0.70±0.03
Tensile strength at MD	N/5cm	GB/T1040	3000
Tensile strength at CD	N/5cm	GB/T1040	2500
Tearing Strength at MD	N/5cm	GB/T16578	300
Tearing Strength at CD	N/5cm	GB/T16578	290
Peeling Strength	N/5cm	GB/T3917	90
Temperature range	ºC		-20 ~ +70
Flame retardancy		NFPA-701,B1 ,B2,M1.M2 ,	Optional
Environmental		E N – 7 1 , R o H s	Optional
MOQ	M	2500LM
Packing		Kraft paper
Lead time		20-25days

Blockout PVC Tarpaulin Applications:

Where is blockout tarpaulin used?

Blockout tarpaulin is ideal as an indoor and outdoor advertising space. A standard application is as banner on construction fences or scaffolds, bridge railings or barriers. In these locations, the material shows its strength and stability under harsh weather conditions. Indoors, the material is mainly used as advertising banner, for example suspended in supermarket aisles, shopping centres or hardware stores.

In which sizes is blockout tarpaulin available?

In our online shop, you can order blockout tarpaulin under the product name “Tarpaulins, 4/4 colours”. You can have the tarpaulin printed on both sides to your size specifications. Just enter your desired size up to 400 cm x 200 cm on the product page in the product configuration section when ordering your blockout tarpaulin. The minimum size is 100 cm x 100 cm.

What is the best way to install blockout tarpaulin?

To make installing the blockout tarpaulin as easy as possible, you can order your tarpaulin fitted with weather-proof eyelets in 50 cm intervals. To do so, go to the “Eyelets” section in the additional options and specify where to apply the eyelets (along the short or long end). You can also choose to have eyelets fitted along all sides of the tarpaulin.
